Turbo TOC Upgrades - Hydraulic & Lubricating Replacement Filters

Fluid Conditioning Upgrades

Turbo-TOC
Upgrades

Multi-stage fluid conditioning — coalesce, separate, and polish to remove water, particulate, and varnish-forming compounds.

Turbo-TOC Upgrades

Overview

Turbo-TOC upgrade kits replace OEM elements in existing lube oil conditioning skids with high-performance filtration and water removal stages. The system addresses particulate contamination, free and emulsified water, and total oxidative compounds (TOC) that contribute to varnish formation in turbine lube and hydraulic systems.

System Stages

Pre-filter: Removes gross particulate to protect downstream coalescer from premature loading
Coalescer: Merges fine water droplets into larger droplets for gravity separation (targets emulsified water down to 20 ppm)
Separator: Hydrophobic barrier allows oil passage while rejecting coalesced water to drain
Post-polish: DFE-rated final stage for particulate removal to ISO 16/14/11 or cleaner

Performance Specifications

Free water removal efficiency >95% single-pass at rated flow
Particulate filtration: β₃[C] ≥ 1000 on post-polish stage
Flow rates: 5–50 gpm depending on skid configuration
Operating viscosity range: 10–320 cSt at operating temperature
Compatible with Group I, II, and III mineral oils and PAO synthetics

Applications

Steam and gas turbine lube oil systems
Combined cycle power generation
Compressor lube systems with water ingression
Paper machine lube oil conditioning
Any system requiring simultaneous water removal and fine filtration

Upgrade Benefits

Direct interchange with existing Turbo-TOC housing configurations
Improved water separation vs. OEM elements in degraded oil conditions
Extended element life through optimized media selection
Reduced varnish potential by lowering dissolved water and oxidation byproducts

Specifications

Stages

Pre-Filter, Coalescer, Separator, Post-Polish

Water Removal

>95% Single-Pass

Filtration Rating

β₃[C] ≥ 1000, ISO 16/14/11

Flow Rate

5–50 GPM

Viscosity Range

10–320 cSt

Fluid Compatibility

Group I/II/III Mineral, PAO Synthetic
